Waste Plastic To Fuel Full Production Line Waste Plastic Pyrolysis 60 Tons Plant
Product description
Nowadays, with human exploitation and environmental degradation, natural energy especially oil energy is becoming less and less, on the contrary, municipal solid wastes are becoming more and more. Huayin waste plastic pyrolysis machine can convert the normal daily wastes like plastic bags, and rubber scraps into fuel oil, which can be used as heating fuel in many industrial fields.
Specification
| Item | Content |
| Raw materials | Waste tyre/rubber |
| Output | 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas |
| Model | Reactor size | Capacity |
| HY1500*3000 | 1 T/batch |
| HY2200*5500 | 5 T/batch |
| HY2200*7500 | 7 T/batch |
| HY2600*6600 | 8 T/batch |
| HY2800*6000 | 9 T/batch |
| HY2800*6600 | 10 T/batch |
| HY2800*8000 | 15 T/batch |
| Remarks | Support customization |
| Reactor material and thickness | Q345R/Q245R/310S (Boiler plate/stainless steel) 16mm/18mm |
| Land area | 300-400㎡ (L30-40m*W10m) |
| Number of workers | 3-4 |
| Oil density and calorific value | 0.89g/cm³&44.30KJ/KG |
| Processing time and power | 10-24 hours. Averagely 15KW/h |
| Certification | CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents
|
Input raw material
The applicable waste raw material includes various kinds of waste tires, car tires, bicycle tires, motorcycle tires, OTR tires, etc.
Various kinds of plastic waste, like PP, PE, PS, ABS, PMMA, etc.
Output product and usage
Fuel Oil (50%-75%)
1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color and smell removal system, the final oil can be used in diesel engines like trucks, tractors, etc.
Carbon Black (30%-35%)
Slag for construction.
Flammable Gas (8%-10%)
1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.
Features
Safety: Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.
Oil-water separator: Its water sealing design ensures that oil and gas are separated and combustible gas can not return to the reactor.
Energy-saving:
The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel.
The combustible gas that cannot be further cooled down into fuel oil will be recycled to the furnace for heating the reactor, maximizing resource utilization.
The cooling water adopts a circulating mode, which is pollution-free, no discharging, and recyclable.
High efficiency discharging: Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution and save labor and time.
Integrated condensing device: All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality.
Auto feeder machine to feed raw material automatically, save labor and time.
FAQ
1. What is the price of one complete set of waste pyrolysis plants?
The price of the pyrolysis plant depends on the configuration, and capacity, please contact us to get the latest quotation.
2. What payment methods do you accept?
A: We can accept T/T, L/C, Western Union.
3. Does waste pyrolysis plants pollute the environment?
With a powerful de-dusting system, the smoke will be desulfurization and purified before being discharged out. SGS emission reported provided.
4. How many countries have your machines been exported to?
HUAYIN equipment has been exported to over 80 countries including Romania, Hungary, Turkey, Slovakia, Ecuador, Guatemala, Haiti, Mexico, Peru, Canada, Jordan, UAE, Lebanon, Italian, Chile, Poland, England, Thailand, Greece, Mexico, Benin, Indonesia, India, Singapore, Russia, etc.
